3
Technical Information
Service Manual
The above data is subject to change without notice. Please refer to the nameplate of the unit.
Outdoor
Unit
Outdoor Unit Model
SOH-09BIK2 SOH-12BIK2
Compressor Manufacturer
ZHUHAI LANDA
COMPRESSOR CO.,LTD
ZHUHAI LANDA
COMPRESSOR CO., LTD
Compressor Model QXF-A082zC170 QXF-N088zC170
Compressor Oil ZE-G;ES RB68GX or equivalent FW68DA or equivalent
Compressor Type Rotary Rotary
Compressor LRA. A 15 /
Compressor RLA A 2.56 3.6
Compressor Power Input W 757 758
Compressor Overload Protector / /
Throttling Method Capillary Capillary
Set Temperature Range ºC 16~30 16~30
Cooling Operation Ambient Temperature Range ºC -15~43 -15~43
Heating Operation Ambient Temperature Range ºC -15~24 -15~24
Condenser Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Condenser Pipe Diameter mm Ф7 Ф7
Condenser Rows-n Gap mm 1-1.2 1-1.2
Condenser Coil Length (LXDXW) mm 666X19.05X527 700X19.05X528
Fan Motor Speed rpm 850 900
Fan Motor Power Output W 30 30
Fan Motor RLA A 0.4 0.4
Fan Motor Capacitor μF / /
Outdoor Unit Air Flow Volume m
3
/h 1950 1950
Fan Type Axial-ow Axial-ow
Fan Diameter mm Ф400 Ф400
Defrosting Method Automatic Defrosting Automatic Defrosting
Climate Type T1 T1
Isolation I I
Moisture Protection IPX4 IPX4
Permissible Excessive Operating Pressure for
the Discharge Side
MPa 4.3 4.3
Permissible Excessive Operating Pressure for
the Suction Side
MPa 2.5 2.5
Sound Pressure Level dB (A) 51 52
Sound Power Level dB (A) 60 63
Dimension(WXHXD) mm 732X555X330 732X555X330
Dimension of Carton Box (LXWXH) mm 791X373X590 791X373X590
Dimension of Package(LXWXH) mm 794X376X615 794X376X615
Net Weight kg 24.5 25
Gross Weight kg 27 27.5
Refrigerant R32 R32
Refrigerant Charge kg 0.5 0.57
Connection
Pipe
Connection Pipe Length m 5 5
Connection Pipe Gas Additional Charge g/m 16 16
Outer Diameter Liquid Pipe inch 1/4 1/4
Outer Diameter Gas Pipe inch 3/8 3/8
Max Distance Height m 10 10
Max Distance Length m 15 20
Note: The connection pipe applies metric diameter.
To Next Page
