16
T
echnical Information
Service Manual
OFF is defaulted. X-FAN is not available in AUTO, FAN or HEAT
mode.
This function indicates that moisture on evaporator of indoor unit
will be blowed after the unit is stopped to avoid mould.
● Having set X-FAN function on: After turning
off the unit by pressing ON/OFF button indoor fan will continue
running for a few minutes. at low speed. In this period, Hold fan
speed button for 2s to stop indoor fan directly.
● Having set X-FAN function off: After turning off the unit by
pressing ON/OFF button, the complete unit will be off directly.
button
Press this button to set up & down swing angle, which circularly
changes as below:
This remote controller is universal. If any command , or is
sent out, the unit will carry out the command as
indicates the guide louver swings as:
button
Press this button to turn on I FEEL function. The unit automatically
adjust temperature according to the sensed temperature. Press
this button again to cancel I FEEL function.
● When I FEEL function is turned on, the remote controller should
be put within the area where indoor unit can receive the signal
sent by the remote controller.
button
Press this button to achieve the on and off of health and
scavenging functions in operation status. Press this button for the
rst time to start scavenging function; LCD displays " ". Press
the button for the second time to start health and scavenging
functions simultaneously; LCD displays " " and " ". Press this
button for the third time to quit health and scavenging functions
simultaneously. Press the button for the fourth time to start health
function; LCD display " ". Press this button again to repeat the
operation above.
Notice
：
● This function is only available for some models.
button
Press this button to go into the Sleep operation mode. Press it
again to cancel this function. This function is available in Cool,
Heat (Only for models with heating function) mode to maintain the
most comfortable temperature for you.
button
Press this button can see indoor set temperature, indoor ambient
temperature or outdoor ambient temperature on indoor unit's
display. Temperature is set circularly by remote controller as
below:
● When selecting " " or no display with remote controller,
temperature indicator on indoor unit displays set temperature.
● When selecting " " with remote controller, temperature
indicator on indoor unit displays indoor ambient temperature.
● When selecting " " with remote controller, temperature
indicator on indoor unit displays outdoor ambient temperature.
Notice
：
● Outdoor temperature display is not available for some models.
At that time, indoor unit receives " " signal, while it displays
indoor set temperature.
● Only for the models whose indoor unit has dual-8 display.
button
Press this button to initiate the auto-ON timer. To cancel the auto-
timer program, simply press this button again.
After press of this button, disappears and "ON" blinks. 00:00
is displayed for ON time setting. Within 5 seconds, press + or
- button to adjust the time value. Every press of either button
changes the time setting by 1 minute. Holding down either button
rapidly changes the time setting by 1 minute and then 10 minutes.
Within 5 seconds after setting, press TIMER ON button to conrm.
button
Press CLOCK button, blinking . Within 5 seconds, pressing +
or - button adjusts the present time. Holding down either button
above 2 seconds increases or decreases the time by 1 minute
every 0.5 second and then by 10 minutes every 0.5 second.
During blinking after setting, press CLOCK button again to conrm
the setting, and then will be constantly displayed.
button
Press this button to initiate the auto-off timer. To cancel the auto-
timer program, simply press the button again. TIMER OFF setting
is the same as TIMER ON.
button
Press this button to activate / deactivate the Turbo function which
enables the unit to reach the preset temperature in the shortest
time. In COOL mode, the unit will blow strong cooling air at super
high fan speed. In HEAT mode, the unit will blow strong heating
air at super high fan speed.
button
Press LIGHT button to turn on the display's light and press this
button again to turn off the display's light. If the light is turned on,
is displayed. If the light is turned off, disappears.
button
Press " WiFi " button to turn on WiFi function, "WiFi " icon will be
displayed on the remote controller;
Hold " WiFi " button for 5s to turn off WiFi function and " WiFi "
icon will disappear.
Under off status, press "MODE" and " WiFi " buttons
simultaneously for 1s, WiFi module will restore factory settings.
NOTE:
● This function only applicable for some models.
