67
Installation and Maintenance
Service Manual
Step Procedure
4. Remove grille
Remove
connection screws between the front grille and
the front panel. Then remove the grille.
5. Remove front panel
R
emove connection screws connecting the front panel
with the chassis and the motor support and then
remove the front panel.
6. Remove right side plate
Remove connection screws connecting
the right side
plate with the valve support and the electric box. Then
remove the right side plate.
grille
front panel
right side plate
To Next Page
