45
wall, and pull this wire through the “ ” hole at the rear side of
the soleplate of wired controller;
(3) Stick the soleplate of wired controller on the wall and then use
screw M4×25 to fix soleplate and installation hole on wall
together;
(4) Connect two-core twisted pair wire to H1 and H2 wiring column
and then fix the screws(it is needn’t to differentiate polarity. );
(5) Block the two-core wire into the groove at the left side of wiring
column; bundle the front panel of wired controller to its
soleplate.
Note:
If the procedures in point 2 and point 5 mentioned above is hard to be done as
the diameter of selected communication wire is big, please peel off the sheathed
layer in appropriate length according to actual situation.
