- 4 -
CZ sincro
DG83 D
2.0 PRELIMINARY INFORMATION
• For the right use of the strobotester, it is necessary to become familiar
with commands and to know some preliminary instructions.
The following chapters contain detailed instructions, while the yellow
sheets contain short form instructions.
• Fig. 1 shows the displays and the keys for selecting measurements.
Special LEDs show the default setting after connecting the unit to
battery as well as the type of measurement selected by the operator.
• Blinking zero shows lack of electrical signal
• The keys in the handle of Fig. 2 are normally used to adjust advance,
activate flash, switch and store measurements.
They can also have different functions, described in the relevant
chapters.
• RPM and ignition advance measurements are carried out by connecting
the inductive clamp to the spark cable of cylinder No. 1 and are
independent from the number of cylinders.
• Readings of injection time, ignition coil charging time, Duty Cycle of
actuators and Dwell in degrees in points systems, are displayed on
display 3 (chap. 4,5,6). See par. ATTENTION on page 7 for checking
the wear of each cam.
• Select the number of sparks per revolution, really existing (Table 1) to
have correct readings.
