User Manual of A90 Series Inverter
231
★
: Unplug the keyboard during JOG running to stop the inverter.
1: Terminal control
Select the digital input terminal function “4: forward jog (FJOG)”
or “5: reverse jog (RJOG)”. By default, if the function terminal is
valid, the jog running command will be valid; and if the function
terminal is invalid, the jog running command will be invalid.
2: Communication
control
If the host writes “0003H: JOG forward” or “0004: JOG reverse”
to the register 7000H through the MODBUS protocol, the jog
running command will be valid; if it writes “0007H: free stop”, the
jog running command will be invalid.
Function
code
Function code name
Parameter description
Unit
Default
setting
Attribute
F15.03
Acceleration time 2
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
F15.04
Deceleration time 2
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
F15.05
Acceleration time 3
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
F15.06
Deceleration time 3
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
F15.07
Acceleration time 4
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
F15.08
Deceleration time 4
0.00 - 650.00 (F15.13=0)
0.0 - 6500.0 (F15.13=1)
0 - 65000 (F15.13=2)
s
15.00
●
F15.09
Fundamental
frequency of
acceleration and
deceleration time
0: maximum frequency
F00.16
1: 50.00Hz
0
○
The system has four groups (F00.14 and F00.15 in the first group) of acceleration and
deceleration time options to meet different needs for normal operation. After completing the
setting, the user can switch them via the combination of digital input functions “19:
acceleration and deceleration time terminal 1” and “20: acceleration and deceleration time
terminal 2”. For details, please see “Table 7-4 Function List of Multi-function Digital Input
