EA180 Series Servo Drive Users Manual
14
Chapter 2 Installation
2.1 Notes for installation
Please pay attention to the following points:
 The cable between the servo drive and servo motor should be kept loose.
 If the cable between the servo drive and servo motor exceeds 20 meters, please thicken the
UVW cables and the encoder cable.
 When fixing the servo drive, the installation direction must follow the instructions, and each
fixing screw must be firmly fastened.
 Make sure the servo motor shaft is concentric with the equipment shaft to prevent radial stress
during operation.
 The four fixing screws of the servo motor must be fastened according to the specified torque.
 In order to have a good cooling effect, when installing the AC servo drive, please keep
enough space between the device and adjacent articles and baffles (walls) around it, otherwise
faults may be caused.
 The servo drive shall not be toppled and placed during installation, and its suction and exhaust
holes shall not be blocked, otherwise faults may be caused.
2.2 Environmental conditions for storage
Please put this product in its packing box before installation. If the servo set is not used for the
time being, in order to make the product conform to the warranty scope and requirements for
future maintenance of SINEE, the following matters must be paid attention to during storage:
Item
Description
Ambient
temperature
-20 ℃ ~ + 65 ℃
Ambient humidity
Relative humidity 20%～90% (no condensation)
Vibration
Below 49m/s²
Shock
Below 49m/s²
2.3 Environment conditions for installation
2.3.1 Operating conditions of EA180 servo drive
Item
Description
Dust and gas
The device must be installed in a dust-free environment without
corrosive gases or liquids.
Ambient humidity
Relative humidity 20%～90% (no condensation)
Ambient temperature
0 ℃ ~ + 45 ℃
Vibration
Below 49m/s²
Shock
Below 49m/s²
Altitude
Below 1000m; if above 1000m, please derate the device
2.3.2 Operating conditions of servo motor
Item
Description
Ambient
humidity
Relative humidity 20%～90% (no condensation)
Ambient
temperature
0℃～+40℃
Vibration
Below 49m/s²
Shock
Below 49m/s²
Altitude
Below 1000m; if above 1000m, please derate the device
 Do not use the motor in a closed environment. Closed environment will lead to high
temperature of motor and shorten its service life.
2.3.3 Other notes
In addition to the above environmental conditions, no matter the servo drive or motor, please
follow the following instructions when selecting the installation location, otherwise the product
may not meet our warranty scope and future maintenance requirements:
