Singer 20U-105C - Fittings for Hem Sewing; Troubleshooting

25
3.24
Figure 34
Buttonhole Foot ‘1’, Needle plate ‘2’
(Zigzag stitch) and Feed Dog ‘3’ are
used for buttonhole stitching.
(Figure
35)
Fittings for
Buttonhole
Stitching
410192 541937-452 543979
606688(20U-105/105C
)
606502(20U-125/125C)
606652(20U-105/105C)
606402(20U-125/125C)
3.25
Figure 3
5
Figure 3
6
The hem foot ‘1’, needle plate ‘2’
(Straight stitch) and feed dog ‘3’ can
turn and stitch a narrow hem in a
single operation as the following
condition. (Figure 36 and 37)
1. Needle position selector:
Center position
2. Stitch width regulate:
Straight stitch position.
Fittings for
Hem Sewing
1
1
606692(20U-105/105C
/125/125C)
2
2
3
3
Zigzag Sewing Machine
|
Instruction Manual and Parts List
