3-5 Needleowatmaximumzigzag
width
- Remove the face plate, back cover and front
cover.
- Set the pattern selector dial to " ".
Turn the stitch width dial to "6".
- Set the needle bar at its lowest point when it
swings to left. Turn hand wheel to move the
needle bar upward.
The vertical distance in which the needle
point goes up at the left position from the top
of the needle plate should be 3-5 mm. (1)
- If needle ow is less than 3-5 mm, loosen the
arm shaft worm screws (a, b), and turn arm
shaft worm (c) toward back (↑). (2)
- If needle ow is more than 5 mm, turn arm
shaft worm (c) toward front (↓). (2)
- Tighten the screws (a, b) after making sure
the needle ow is 5 mm.
3-5mm
