Singer 4432 - Distance-Needle-Hook


3-12 Distance-needle-hook
- Remove the face plate, front cover, back
cover and needle plate.
- Set the pattern selector dial to " ".
Turn the stitch width dial to "6".
- Take off the shuttle hook.
- Set the needle towards the lowest point
of right side and lift it, make sure space
between needle and the tip of the shuttle
hook holder is 0.05~0.10mm. (1)
- If the space is incorrect:
Loosen the screw (a) of the needle bar
supporter.
Push the needle bar supporter (b) backward
(↑), and the space will become larger.
Push the needle bar supporter forward (↓),
and the space will become smaller. (2)
