Singer 4432 - Height Of Needle Bar


3-10 Height of needle bar
- Remove the needle plate.
- Set the pattern selector dial to " " or " ".
Turn the stitch width dial to "0".
- Remove the screws of rotary hook plate (a,
b) and rotary hook plate, and take out the
shuttle hook (c). (1)
- Set the needle bar at its lowest point. The
gap between the upper end of the needle
and the surface (d) of the hook ring should
be 28.5 mm. (2)
- If it's not t the standard of measure, loose
the needle bar bracket (f) to adjust the
needle bar's (e) position for measuring the
correct height of needle bar. (3)
d
28.5 mm
