Singer 4432 - Position Of Feed-Dog In Relation To The Needle Plate (Left To Right)


3-16 Position of feed-dog in relation
to the needle plate (left to right)
- Remove the cord reel cover and free arm
cover.
- Loosen the screw (e) of the feed crank shaft
(d) that is on the right side. (1)
- Loosen the screw (b) of the feed crank shaft
(c) that is on the left side. (1)
- Adjust the feed dog to center position by
moving feed crank shaft (c) left / right in
accordance with feed rock shaft (a) left /
right. (2)
- Tighten the screw (b) to fix the left side of
feed crank shaft (c).
- Push right side feed crank shaft (d) to left
and fasten the screw (e).
