Switch Board – 4 (for 7428)
Component number is 87564.
Be sure to check number printed on board.
13P Connector
Connect with CPU
4P Connector
Connect with CPU
4P Connector
Connect with CPU
Twin needle select
SW & needle stop
select SW
64
12 Switches
