6
20
24 25
26
27
28
29
33 34
35
36
37 38
39
40 41
32
31
30
21 22
23
Top Parts
20. Presser foot pressure dial
21. Thread guides
22. Spool caps
23. Attachment for auxiliary spool pin /
Bobbin winding spindle
24. Take-up lever
25. Thread tension discs
26. Bobbin winding tension disc
27. Thread tension dial
Rear Side
28. Main switch, connectors for power cord
and foot control
29. Handle
30. Presser foot lifter
31. Integrated Even Feed System
32. Switch for lowering the feed teeth
Accessories
Included Accessories
33. Bobbins (5) (SINGER
®
Class 15
transparent bobbins)
34. Felt pad
35. Screwdriver for needle plate
36. Clearance plate
37. Spool cap, large (2)
38. Spool cap, small
39. Seam ripper & brush
40. Edge/quilting guide
41. Auxiliary spool pin
Included Accessories Not in Picture
• Foot control
• Power cord
• Needles
• Hard cover
