104 73 97-26 S0100 / S0105 5
15. Remove the the screw that holds the thread
undwinder (J).
16. Remove the two screws (K) on the cylinder
cover.
Remove the cylinder cover
17. When removing the cylinder cover unhook the
hooks ((L)
18. Remove the back cover screw (M).
Remove the back cover.
19. Remove the four screws (O).
Remove the motorcover screw (P).
Remove the two safty swyítch screws
(Q).
J
M
O
Q
P
K
L
