© Jul 2020 1-2 GTJZ0612&0812&1012&1212 Operation Manual
PERFORMANCE PARAMETERS
Table 1-1 GTJZ0612 Specifications (continued)
MEASURE
GTJZ0612 (METRIC) 2146 (IMPERIAL)
Max. allowable manual force (indoor/
outdoor)
400N 90 lbf
Max. noise 72dB
POWER PARAMETERS
Hydraulic tank capacity 15L 3.3 gal(imperial)/4 gal(US)
Hydraulic system capacity (including tank) 20L 4.4 gal(imperial)5.3 gal(US)
Hydraulic system pressure 24MPa 3046 psi
Battery specification (quantity × voltage,
capacity)
4×6V, 240Ah
System voltage
24 VDC
Control voltage
24 VDC
ENVIRONMENTAL REQUIREMENT
Max. allowable wind speed (indoor/
outdoor)
0m/s(indoor)/12.5m/s(outdoor) 0 mph(indoor)/28 mph(outdoor)
Max. allowable altitude 1000m 3280.8ft
Allowable ambient temperature (lead-acid
batteries)
-10℃ to 40℃ 14℉ to 104℉
Allowable ambient temperature (lithium
batteries)
-20℃ to 40℃ -4℉ to 104℉
Max. allowable ambient relative humidity
90%
Storage condition
Stored at -20℃ to 50℃(-4℉ to 122℉) in a well-ventilated environ-
ment with 90% relative humidity (20℃ [68℉]), and away from rain,
sun, corrosive gas and inflammable explosive.
WEIGHT
Weight (in a no-load state) (indoor/
outdoor)
2415kg
5325 lb
Table 1-2 GTJZ0812 Specifications
MEASURE
GTJZ0812 (METRIC) 2746 (IMPERIAL)
DIMENSION PARAMETERS
Max. platform height
8.1m 26ft 7in.
Max. working height
10.1m 33ft 2in.
Max. horizontal extension 0.9m 3ft
Length
2.45m 8ft
Width 1.17m 3ft 10in.
Height (stowed, rails folded)
1.73m 5ft 8in.
