SIP 01444 - Technical Specifications; Accessories; Exploded Drawing (B)

10
ACCESSORIES
Bearing guide hand-wheel.
Belt tension hand-wheel.
Main table.
Rip-fence guide rail.
Rip fence.
Auxiliary fence (Rip-fence).
Mitre gauge.
Auxiliary fence (mitre gauge).
NVR switch cover.
Cabinet stand - 1 x bottom panel, 1 x front panel, 1 x rear panel, 2 x side panels and
1 x fixing kit.
IF ANY OF THE ABOVE ITEMS ARE MISSING or DAMAGED; CONTACT YOUR
DISTRIBUTOR IMMEDIATELY.
Part number 01444
Input voltage 230v ~ 50hz
Power 1500 watts (2 hp)
Minimum speed (no load) 8m/sec.
Maximum speed (no load) 14m/sec.
Blade length 2750 mm
Blade width 6 mm-25 mm
Maximum work-piece height 235 mm
Maximum cutting width 345 mm
Table size 435 mm x 535 mm
Table height (with stand) 49” (1250 mm)
Table tilt angle (maximum) 45°
TECHNICAL SPECIFICATIONS
31
EXPLODED DRAWING (B)
