14
ASSEMBLY INSTRUCTIONS
Assembling the cabinet stand:
27
MAINTENANCE….cont
• Place the new drive belt over the pulley on the main drive-wheel.
• Re-fit the drive-wheel to the saw and fully tighten the lock nut to secure.
• Follow the instructions on pages 17 and 19 to re-fit the blade and to re-tension
the drive belt.
Cleaning:
⇒ Always remove excess chippings and waste debris from the band-saw, pay par-
ticular attention around the motors air inlets, failure to do so could result in
overheating and even fire.
⇒ Periodically clean and lubricate the internal moving parts of the band-saw such
as the rack and pinion blade guide assembly, belt tension screw, table tilting as-
sembly and the belt tension assembly to ensure easy accurate adjustments.
