Ref. Description Ref. Description
A. Blade Tension Fine Adjustment
Hand-wheel
K. Rip Fence
B. Blade Tension Indicator Window L. Blade Guide Locking Knob
C. Main On / Off Switch (NVR) M. Blade Tension Quick Release Lever
D. Cabinet stand N. Blade Tracking Knob
E. Belt Tension Hand-wheel O. Blade Tracking Lock Lever
F. Rip-fence Micro Adjust Knob P. Table Tilt Knob
G. Rip-fence Locking Handle Q. Motor
H. Mitre Gauge R. 4" Dust Extraction Port
I. Blade Guide (rack and pinion) S. Mains Lead
J. Blade Guide Rise / Fall Hand-wheel T. Table Tilt Locking lever
GETTING THE KNOW YOUR BAND SAW….cont
Guarantee:
This saw is covered by a 36 month parts and labour warranty covering failure due to
manufacturers defects. This does not cover failure due to misuse or operating the ma-
chine outside the scope of this manual.
In the unlikely event of warranty claims, contact your distributor or contact our help
line on the back page of this manual.
Proof of purchase will be required before any warranty can be hon-
oured.
GUARANTEE
29
TROUBLESHOOTING….cont
Problem Possible Cause Remedy
Sawdust builds up inside
the machine:
• This is normal.
• Regularly clean out
sawdust from all areas
of the saw. Use of an
adequate dust extractor
will minimize this issue.
Table saw vibrates exces-
sively:
• Floor surface is uneven.
• V-belt is damaged.
• Saw blade is damaged.
• Loose bolt, Screws,
Nuts.
• Sit the saw on a level
surface.
• Replace the V-belt.
• Replace the Saw Blade.
• Tighten all Hardware.
Fuses or circuit breakers
blow or open frequently:
• Motor is overloaded.
• Fuses or circuit breakers
are wrong size or defec-
tive.
• Dull saw blade.
• Power Switch or motor
is defective.
• Feed work-piece more
slowly.
• Replace fuses or circuit
breakers.
• Replace the saw blade.
• Have the Power Switch
or motor checked, re-
paired or replaced.
To Next Page
