34
PARTS LIST….cont
Ref. Description Ref. Description
57. Saw blade 85. Hex nut MI6
58. Lower wheel 86. Cross pan head screw M5 x 16
59. Pulley drive 87. Mount, pointer
60. Belt "A" 88. Hex nut M5
61. Dual thread screw, bracket 89. Hand wheel
62. Shaft, lower wheel 90. Thread, tension
63. Bracket, lower wheel 91. Spring washer 8 mm
64. Ring circle 12 mm 92. Lock lever, wheel tilt
65. Washer 12 mm 93. Lock, flower screw
66. Bearing 80101 94. Parallel pin
67. Ring circle 28 mm 95. flat washer 6 mm
68. Tension pulley 96. Allen bolt M6 x 12
69. Shaft, tension pulley 97. Screw, indicator
70. Collar, tension rod 98. Indicator
71. Screw set M6 x 8 99. Lock eccentric
72. Thread, tension rod 100. Lever, lock eccentric
73. Allen bolt M5 x 30 101. Table insert
74. Hand wheel, tension 102. Table
75. Spacer 103. Hex nut M8
76. Motor pulley 104. Hex screw M8 x 70
77. Screw set M5 x 10 105. Tilt rack
78. Key flat 106. Cross pan head screw M5 x 6
79. Motor 107. Carriage bolt M8 x 80
80. Saw frame 108. Rack, table trunnion
81. Spring washer 12 mm 109. Table trunnion, upper
82. Cap nut M12 110. Allen bolt M10 x 30
83. Spring washer 8 mm 111. Table trunnion, lower
84. Washer 16 mm 112. Flower screw, lower guide
7
22. Do not modify the saw to do tasks other than those intended.
23. Keep the site free of tripping hazards. Ensure adequate lighting conditions.
24. The saw must only be operated with all correctly mounted guards etc.
25. Never use cracked or distorted saw blades - Only user sharp saw blades.
26. Use a push stick when rip sawing narrow work-piece.
Blade Safety:
• Use only blades that are recommended by the manufacturer.
• Do Not use blades that are deformed or have missing teeth, this is highly dan-
gerous and could result in a serious accident to the operator and bystanders as
well as damaging the machine.
• Only use blades that are recommended by the supplier and that are in good con-
dition.
• Ensure that the directional arrow, if marked on the blade corresponds with the
rotational direction of the motor, the teeth of the blade should always point
downward when viewed from the front of the saw.
• Always release the blade tension, when the machine is not in use.
• Always wear gloves and eye protection when fitting or removing blades.
• Always uncoil blades in spacious areas, away from other people, and take great
care.
• Always keep looped blades secure with tie wires.
• Always keep fingers away from moving blades.
Use of extension leads:
• DO NOT use 2 core extension leads or reels, always use a 3 core extension lead
or reel with an earth.
• Always unwind any extension leads fully.
• For extension leads up to 15 metres use a wire cross section of at least 1.5
mm².
• For extension cords over 15 metres but less than 40 metres use a wire cross
section of at least 2.5 mm².
• Always replace a damaged extension lead before using the band saw.
• Protect your extension cord from sharp objects, excessive heat and damp or wet
locations.
CAUTION: The warnings and cautions mentioned in this user manual
can not cover all possible conditions and situations that may occur. It
must be understood by the operator that common sense and caution are
factors which cannot be built into this product, but must be applied.
SPECIFIC SAFETY INSTRUCTIONS….cont
