PARTS LIST (C)
Ref. No. Description Qty.
C-30 Square Nut M6 4
C-31 Cross Recessed Pan Head Screw M6 X 16 4
C-32 Board Instead Of Nut 1
C-33 Cross Recessed Countersunk Screw 6
C-34 Left End Cap For Scale Indicator Housing 1
C-35 Scale Indicator Housing 1
C-36 Right End Cap For Scale Indicator Housing 1
C-37 Scale Indicator 1
C-38 External Teeth Lock Washer 5 3
C-39 Cross Recessed Pan Head Screw M5 X 10 3
C-40 Square Nut M5 3
C-41 Small Gear 1
C-42 Gear Rod 1
C-43 Eccentric Wheel 1
C-44 Gear Rod Frame 1
C-45 Spring For Gear Rod 1
C-46 Hexagon Socket Set Screw With Flat Point M6 X 5 2
C-47 Rip Fence Handle 1
C-48 Rear Board 1
C-49 Pin 5 X 16 2
C-50 Rear Block 1
C-51 Lock Eccentric Rod 1
C-52 Lock Eccentric 2
C-53 Rip Fence Lock Rod 1
C-54 Rip Fence Handle 1
C-55 Rip Fence Cover 1
C-56 L-Shape Fence 1
C-57 Step Bolt M6 X 70 2
C-58 Large Washer 6 2
C-59 Wing Nut M6 2
3
CONTENTS
Page No. Description
3. Contents
4. General Safety Instructions
6. Specific Safety Instructions
7. Safety Devices
7. Safety Symbols
8. Safety Symbols Used Throughout This Manual
8. Technical Specifications
9. Accessories
10. Getting To Know Your Saw
11. Specified Conditions Of Use.
11. Guarantee
12. Electrical Connection
13. Assembly Instructions
22. Operating Instructions
25. Care And Maintenance
29. Troubleshooting
31. Optional extras
32. Exploded diagram (A)
33. Parts list (A)
35. Exploded diagram (B)
36. Parts list (B)
40. Exploded diagram (C)
41. Parts list (C)
43. Declaration Of Conformity
