34
PARTS LIST (A)
Ref. No. Description Qty.
A-43 Switch House 1
A-44 Switch 1
A-45 Washer 4 9
A-46 Cross Recessed Pan Head Screw M4 X 10 7
A-47 Tie-In 1
A-48 Hexagon Nut M6 4
A-49 Hexagon Head Bolt M8 X 12 28
A-50 Washer 8 57
A-51 Hexagon Nut M8 28
A-52 Stand Level Foot 4
A-53 Front Panel For Stand 1
A-54 Rear Panel For Stand 1
A-55 Left Side Panel For Stand 1
A-56 Right Side Panel For Stand 1
A-57 Cross Recessed Countersunk Head Screw M6 X 16 4
A-58 Cross Recessed Countersunk Screw 2
A-59 Switch Bottom Board 1
A-60 Lock Nut M8 1
A-61 Knob 1
A-62 Copper Washer 6 2
A-63 Strain Relief M20 1
A-64 Wire Strain 1
A-65 Washer 5 1
A-66 Cross Recessed Countersunk Head Screw M5 X 18 1
A-67 External Teeth Lock Washer 5 1
A-68 Earth-Plate 1
A-69 Hexagon Nut M6 1
A-70 Mounting plate for mobile wheel kit 1
11
SPECIFIED CONDITIONS OF USE
Guarantee:
This sip “pro” table saw is covered by a 24 month parts and labour warranty covering
failure due to manufacturers defects. This does not cover failure due to misuse or op-
erating the machine outside the scope of this manual.
In the unlikely event of warranty claims, contact your distributor or contact our help
line on the back page of this manual.
GUARANTEE
• This machine is intended to rip and crosscut grown timber, faced boards, chip
board, wood-core plywood sheets and similar wood-derived materials.
• Do not cut round stock without suitable jigs or fixtures, the rotating saw blade
could turn the work-piece.
• When sawing thin stock on edge, a suitable guide must be used for firm support.
• The use of wobble (or similar) type saw blades is not permitted on this machine.
Note: Proof of purchase will be required before any warranty can be hon-
oured.
• Use not specified, alteration of the saw or use of parts that are not approved by
the equipment manufacturer can cause unforeseen damage and / or personal
injury to the operator as well as those in the working area.
Caution: Use, other than that specified is not permitted.
