12
ELECTRICAL CONNECTION
Connecting to the power supply:
This sip “pro” table saw is supplied without a plug fitted; due to the fuse rating (16
amps) the saw is not classed as a “domestic item”. A plug with a rating of at least 16
amps (and an adequate supply) will have to be fitted prior to use, alternatively the saw
could be hard wired into an adequate supply. Each time you use your saw inspect the
cable and plug to ensure that neither are damaged. If any damage is visible have the
tool inspected / repaired by a suitably qualified person.
The wires for the plug are coloured in the following way:
Yellow / green Earth
Blue Neutral
Brown Live
As the colours of the wires may not correspond with the markings in your plug, pro-
ceed as follows: The wire which is coloured blue, must be connected to the terminal
marked with N or coloured black. The wire which is coloured brown, must be con-
nected to the terminal, which is marked L or coloured red. The wire which is coloured
yellow / green should be connected to the terminal which is coloured the same or
marked
Always secure the wires in the plug terminal carefully and tightly. Secure the cable in
the cord grip carefully.
Note: Always make sure the mains supply is of the correct voltage and the
correct fuse protection is used. In the event of replacing the fuse always use
a 16A fuse.
Note: If an extension lead is required in order to reach the mains supply;
ensure that this too is rated for the correct voltage and fuse rating (16
amps).
Note: The cross section of the extension lead should be checked so that it
is of sufficient size so as to reduce the chances of voltage drops.
Warning: Never connect live or neutral wires to the earth terminal of the
plug. Only fit an approved plug with the correct rated fuse (16 amp). If in
doubt consult a qualified electrician.
33
PARTS LIST (A)
Ref. No. Description Qty.
A-1 Rear Rail 1
A-2 Step Bolt M8 X 25 9
A-3 Cross Recessed Countersunk Head Screw M5 X 6 5
A-4 Insert 1
A-5 Worktable 1
A-6 Extension Table 2
A-7 Washer 8 16
A-8 Hexagon Nut M8 7
A-9 Hexagon Head Bolt M8 X 20 8
A-10 Slotted Set Screw With Flat Point M10 X 80 4
A-11 Hexagon Nut M10 12
A-12 Cross Recessed Pan Head Screw 6
A-13 Washer 4 6
A-14 Left End Cap For Front Rail 1
A-15 Front Rail 1
A-16 Right End Cap For Front Rail 1
A-20 Cross Recessed Pan Head Screw M5 X 8 12
A-21 Washer 6 1
A-22 Hexagon Socket Cap Head Screw M6 X 15 1
A-23 Neck Chain 2
A-24 Dust Collection Tube 1
A-29 Nut Board 2
A-34 Square Nut M5 12
A-35 Rack 4
A-36 External Teeth Washer 5 12
A-37 Base 1
A-38 Left Side Panel For Base 1
A-39 Right Side Panel For Base 1
A-40 Washer 6 14
A-41 Hexagon Socket Cap Head Screw M6X20 6
A-42 Rubber Washer Of Switch House 1
