8
TECHNICAL SPECIFICATIONS
Part number 01446
Input voltage 230v / 50 hz
Input fuse rating 16 amps
Power 3000 watts
Maximum speed (no load) 4000 rpm
Blade outside Ø 315 mm
Blade bore Ø 30 mm
Blade tilt 0° - 45°
Main table size 800 mm (D) x 600 mm (W)
Table working height 860 mm
Extension table size 800 mm (D) x 440 mm (W)
Cutting capacity @ 0° 100 mm
Cutting capacity @ 45° 80 mm
SAFETY SYMBOLS USED THROUGHOUT THIS MANUAL
Danger / Caution: Indicates risk of personal injury and/or the possibil-
ity of damage.
Warning: Risk of electrical injury or damage!
Note: Supplementary information.
Drawing-in / trapping hazard! Risk of personal injury to body parts or
clothing by being drawn into the rotating saw blades.
37
Ref. No. Description Qty.
B-32 Cross Recessed Countersunk Head Screw M8 X 30 1
B-33 Hexagon Head Bolt M8 X 65 1
B-34 Locking Nut For Motor Base 2
B-35 Motor Base 1
B-36 Hexagon Socket Cap Head Screw M5 X 12 2
B-37 Large Washer 5 4
B-38 Hand Wheel 2
B-39 Handle 2
B-40 Handle Bolt 2
B-41 Hexagon Socket Pan Head Screw M6 X 16 4
B-42 Flat Washer 6 12
B-43 Ball Bracket 1
B-44 Thread Rod Ball 1
B-45 Spring Dowel 4 X 28 1
B-46 Adjusting Thread Rod 1
B-47 Worm-Wheel Connecting Rod Nail A 1
B-48 Worm-Wheel Connecting Rod 1
B-49 Worm-Wheel Connecting Rod Nail B 1
B-50 Connecting Rod Bush 1
B-51 Hexagon Nut M6 6
B-52 Adjusting Frame 1
B-53 Cir-clip For Shaft D=24 2
B-54 Knuckle 1
B-55 Thin Nut M12 2
B-56 Height Adjustment Rod 1
B-57 Cross Recessed Countersunk Head Screw M5 X 32 1
B-58 Motor 1
B-59 Hexagon Head Bolt M8 X 40 6
B-60 Key 8X7X50 1
B-61 Hexagon Socket Set Screw With Flat Point M6X9 1
B-62 Hexagon Socket Set Screw With Flat Point M6X6 1
PARTS LIST (B)
To Next Page
