36
PARTS LIST (B)
Ref. No. Description Qty.
B-1 Blade Nut M16 (Left Hand) 1
B-2 Outer Blade Washer 1
B-3 Blade 1
B-4 A-Belt 1
B-5 Pulley 1
B-6 Key (A-Type) 1
B-7 Arbor Shaft 1
B-8 Bearing 80203 2
B-9 Arbor Shaft Sleeve 1
B-10 Arbor Shaft Bush 1
B-11 Cir-clip For Hole D=40 2
B-12 Arbor Shaft End Bush 1
B-13 Press Wheel 1
B-14 Single Coil Spring Lock Washer 6 1
B-15 Hexagon Head Bolt M6 X 16 1
B-16 Hexagon Head Bolt M8 X20 4
B-17 Flat Washer 8 18
B-18 Press Board For Riving Knife 1
B-19 Riving Knife 1
B-20 Flower Nut 1
B-21 Large Washer 6 1
B-22 Step Bolt M6 X 46 1
B-23 Blade Guard 1
B-24 Hexagon Nut M8 11
B-25 Hexagon Socket Set Screw With Flat Point M8 X 25 4
B-26 Hexagon Socket Cap Head Screw M10 X 30 1
B-27 Locking Nut With Plastic Insert M8 2
B-28 Riving Knife Bracket 1
B-29 Connecting Rod 1
B-30 Cross Recessed Countersunk Screw M8 X 20 1
B-31 Bush 1
9
ACCESSORIES
Main saw assembly.
Main saw base (4 pieces, 2 x side panels, 1x front panel and 1 x rear panel = 1 set).
Feet (4 pieces = 1 set).
2 x Table extensions.
Mitre gauge.
Auxiliary fence (mitre gauge).
Rip fence.
Auxiliary fence (rip-fence).
Rip-fence micro adjust assembly (inc. fixing bolts).
Front rail.
Rear rail.
Blade guard.
Fixing kit.
Extraction hose outlet adaptor (inc. 4 x screws, nuts and bolts).
Internal extraction hose (larger Ø).
Outlet to blade guard extraction hose (smaller Ø).
2 x Pipe clips (larger Ø).
2 x Pipe clips (smaller Ø).
Arbor nut wrench.
Arbor lock shaft.
Push stick.
Mounting plate for mobile wheel kit (SIP Part no. 06920) *
Fixing kit (nuts, bolts etc).
* The wheel kit is an optional extra and is not supplied with this saw as standard
equipment.
IF ANY OF THE ABOVE ITEMS ARE MISSING or DAMAGED; CONTACT YOUR
DISTRIBUTOR IMMEDIATELY.
Caution: To avoid damage or injury, do not attempt to assemble or use
the saw if any parts are missing or damaged.
