GETTING TO KNOW YOUR SAW
Ref: Description Ref: Description
A. Extension Table G. Front Fence Rail
B. Mitre Gauge H. Rip-Fence
C. Main ON/OFF (NVR) Switch I. Rear Fence Rail
D. Blade Height Adjustment J. Blade guard
E. Blade Angle Adjustment K. Extraction Hose
F. Fence Micro Adjust
J I
A
C
D
F
H
B
E
G
K A
35
EXPLODED DIAGRAM (B)
