NOTE: It is recommended that sharpening is done professionally, using a jig, as blades must be
sharpened as a pair to ensure they are correctly balanced. This avoids the possibility of vibration due to
unbalanced cutters rotating at speed.
Drive Belt Replacement
1. Remove the front cover - 3 nuts.
2. Remove the worn or broken drive belt.
3. Place the replacement drive belt over the small belt wheel.
4. Position part of the drive belt over the large belt wheel.
5. Rotate the large belt wheel by hand in a clockwise direction whilst guiding the belt on to the belt
wheel.
18
MAINTENANCE Cont.
Fig. D
