SIP 01557 - Getting to Know Your Planer Thicknesser

GETTING TO KNOW YOUR PLANER THICKNESSER
2
1312
14
118 9
6
5
4 3
1
7
10
12
13
15
Item No Description Item No Description
1 Overload 9 Planing Blade Guard Assembly
2 NVR On / Off 10 Adjustor
3 Inter– Lock Switch Tongue 11 Adjustment Screw
4 M6 Hand Knob 12 Thicknessing Crank Handle
5 Extraction Chute with Expander 13 Planing Cut Adjustment Knob
6 Guard Pivot Bolt 14 Infeed Table
7 Outfeed Table 15 Planing Depth Gauge
8 Adjustable Fence
9
