Place the cutter setting tool, as shown in the picture, on the knife block. Make sure that the knife touches both
sides of the blade adjustment block.
A
Make sure that the switch is in off position before adjusting the cutting depth, replacing or adjusting the
blades. Make sure the blade screws are securely tightened and the table is free of nails, screws and staples
etc., before use.
Loosen the lock handle A to adjust the fence angle.
14
OPERATING INSTRUCTIONS
SETTING THE ANGLE FENCE
SETTING THE CUTTER BLADE
1,1 mm
Cutter Setting Tool
DUST EXTRACTION REQUIRED!
