Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
172. Bearing cover WK04-00124 192. Nut M8 WK04-00015
173. Circlip WK04-00125 193. Motor key WK04-00138
174. Bearing 6003ZZ WK04-00126 194. Belt guard screw WK04-00139
175. Oil seal 35x17x7 WK04-00127 195. Belt guard WK04-00140
176. Worm sleeve WK04-00128 196. Pulley screw M8x10 WK04-00141
177. Worm shaft WK04-00129 197. Worm pulley WK04-00142
178. Side support WK04-00130 198. Pulley screw M8x10 WK04-00141
179. Washer M6 WK04-00011 199. Motor pulley WK04-00143
180. Bolt M6x12 WK04-00038 200. Belt WK04-00144
181. Motor plate holder WK04-00131 201. Washer M6 WK04-00011
182. Bolt M8x40 WK04-00132 202. Bolt M6x12 WK04-00038
183. Washer M8 WK04-00014 203. Vertical table WK04-00145
184. Washer M8 WK04-00014 N/A QF1 Breaker 1ph WK04-00146
185. Bolt M8x20 WK04-00068 N/A QF1 Breaker 3ph WK04-00147
186. Bolt M8x50 WK04-00133 N/A QF2 Breaker 1 & 3ph WK04-00148
187. Nut M8 WK04-00015 N/A QF3 Breaker 1 & 3ph WK04-00149
188. Motor plate WK04-00134 N/A Contactor CN6 1 & 3ph WK04-00150
189. Motor 1ph WK04-00135 N/A
Thermal relay 1ph
5.5-8.5A
WK04-00151
189. Motor 3ph WK04-00136 N/A
Thermal relay 3ph
2.4-3.6A
WK04-00152
190. Bolt M8x25 WK04-00137 N/A Transformer 1 & 3ph WK04-00153
191. Washer M8 WK04-00014 N/A Blade guard microswitch WK04-00154
5
SAFETY INSTRUCTIONS….cont
supply.
KEEP WORK AREA CLEAN AND WELL LIT: Cluttered work areas and dark areas invite ac-
cidents. Floors must not be slippery due to oil, water or sawdust etc.
HAVE YOUR BANDSAW REPAIRED BY A QUALIFIED PERSON: The bandsaw is in accord-
ance with the relevant safety requirements. Repairs should only be carried out by
qualified persons using original spare parts, otherwise this may result in considerable
danger to the user and void the warranty.
DANGER! Check that the bandsaw is in sound condition and good working order be-
fore each use; Take immediate action to repair or replace faulty / damaged parts.
WARNING! Only operate on a level and stable surface.
WARNING! RISK OF ELECTRIC SHOCK. Do not expose the bandsaw to water spray, rain,
dripping water or moisture of any kind.
PROTECT YOURSELF FROM ELECTRIC SHOCK: When working with power tools, avoid
contact with any earthed items (e.g. pipes, radiators, hobs and refrigerators, etc.). It is
advisable wherever possible to use an RCD (residual current device) at the supply
socket.
DO NOT ABUSE THE MAINS LEAD: Never pull the mains lead to remove the plug from
the mains socket, or to move the bandsaw from place to place. Keep the mains lead
away from heat, oil and sharp edges. If the mains lead is damaged, it must be re-
placed by the manufacturer or its service agent or a similarly qualified person in order
to avoid unwanted hazards.
ALWAYS check that the belt guard and blade guards are in place, adjusted correctly,
undamaged and firmly attached.
NEVER STAND ON THE BANDSAW: The bandsaw is not designed for this purpose.
DO NOT dismantle, tamper with or modify the bandsaw, as this may be dangerous
and will invalidate the warranty.
SECURE THE WORK-PIECE: Use the vice to hold the work-piece; this frees up both hands
to operate the saw.
REMOVE ADJUSTING KEYS AND WRENCHES: Form a habit of checking to see that keys
and adjusting tools are removed from the bandsaw before every use.
If a problem with the bandsaw is experienced or suspected stop using the bandsaw
immediately and contact your distributor for repair.
Regularly inspect the bandsaw, ensuring that it is in good working order and condi-
tion.
Always ensure that the work area is clean, tidy and free from unrelated materials.
Keep away from flammable objects, materials & surfaces, use in a location where
accidental contact (particularly by children) is unlikely.
Ensure on/off switches are switched to off (0) before connecting mains lead to the
power supply.
Keep the work area clean and clear of possible tripping hazards.
Keep children and unauthorised persons away from the bandsaw, as it has a sharp
blade!
Disconnect from the mains before moving or attempting any cleaning or mainte-
