SAFETY INSTRUCTIONS….cont
nance.
Keep hands and all other body parts away from the blade.
Failure to follow the warnings in this manual, may result in personal injury and/or
property damage.
Turn the bandsaw off and disconnect it from the mains supply when moving from
one location to another.
Never operate the bandsaw without all guards in place.
DO NOT get the bandsaw wet or use in damp or wet locations or areas where there
is condensation.
DO NOT move the bandsaw whilst in operation.
DO NOT remove the blade guard or belt guard whilst the bandsaw is switched on.
DO NOT allow unqualified persons to disassemble the bandsaw for any reason, the
bandsaw must be checked by qualified personnel only.
DO NOT use the bandsaw without the blade guard and belt guard closed, as this
will lead to personal injury to you or others!
Warning if a fuse blows, ensure it is replaced with the correct fuse type and rating.
DO NOT place any objects on the safety guard or on the covers at any time.
When not in use, store the bandsaw carefully in a safe, dry, childproof location.
NEVER cover the bandsaw during operation or whilst it cools after operation.
Be aware of moving parts that occur during normal operation of this bandsaw.
NEVER operate the bandsaw with damaged, broken or missing parts, or with any
guards or covers removed.
DO NOT operate the bandsaw or any electrical items with wet hands.
Keep the floor around the machine clean and free of scrap material, oil and
grease.
ALWAYS keep the machine guards in place at all times when the machine is in oper-
ation, if removed for maintenance then use extreme caution, always refit the guards
immediately after any maintenance.
DO NOT over reach, always maintain a balanced stance so that you do not fall or
lean into any moving parts.
Keep all visitors at a safe distance.
ALWAYS keep hands and fingers away from the blade when in operation.
ALWAYS use the vice to secure your material, never cut any material without using
the vice; this is extremely dangerous!
ALWAYS have the belt guard closed at all times when the machine is in operation,
failure to do this can lead to personal injury.
ALWAYS use adequate roller stands for supporting longer and heavier materials.
ALWAYS use the correct blade, using the correct tpi blade for cutting the material will
make your job easier, and the blade last longer, using the wrong tpi blade will make
a rough cut and will decrease the life of the blade.
NEVER force the blade through the material, this will decrease the life of the blade.
ALWAYS keep the bandsaw as clean as possible and keep blades sharp for best
31
PARTS LIST….cont
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
117. Bolt M8x35 WK04-00082 144-1. Sleeve A WK04-00102
118. Washer M8 WK04-00014 144-2. Sleeve B WK04-00103
119. Adjustable bracket WK04-00083 144-3. Sleeve C WK04-00104
120.
Adjustable
bracket screw
WK04-00084 145. Spring WK04-00105
121. Copper pipe WK04-00085 146. Bolt M6x6 WK04-00028
122. Bolt M6x6 WK04-00028 147. Switch WK04-00106
123. Copper pipe support WK04-00086 148. Bolt M10x25 WK04-00107
124. Coolant tap WK04-00087 149. Washer M10 WK04-00046
125. Bolt M8x30 WK04-00018 150. Key 6x25 WK04-00108
126. Nut M10 WK04-00052 151. Bushing WK04-00109
126.1. Washer M10 WK04-00046 152. Gearbox housing WK04-00110
127. Pin WK04-00088 152.1. Bolt M8x16 WK04-00013
128. Bolt M4x6 WK04-00089 153. Bearing 6005ZZ WK04-00111
129. Bearing 608ZZ WK04-00090 154. Circlip WK04-00112
130. Fixed bearing shaft WK04-00091 155. Oil seal 47x25x7 WK04-00113
131. Eccentric bearing shaft WK04-00092 156. Seal WK04-00114
132. Bearing 608ZZ WK04-00090 157. Worm gear shaft WK04-00115
133. Washer M8 WK04-00014 157.1. Key 6x25 WK04-00116
134. Bolt M5x12 WK04-00093 158. Circlip WK04-00117
135. Front plate WK04-00094 159. Worm gear WK04-00118
136. Bolt M8x30 WK04-00018 160. Gearbox cover gasket WK04-00119
137. Right guide holder WK04-00095 161. Gearbox cover WK04-00120
137.1. Left guide holder WK04-00096 162. Washer M6 WK04-00011
138. Right guide bracket WK04-00097 163. Bolt M6x20 WK04-00016
139. Large washer M10 WK04-00098 164. Oil drain bolt WK04-00121
140. Bolt M10x40 WK04-00056 168.
Upper support for
hydraulic cylinder
WK04-00122
141. Bolt M5x10 WK04-00099 169. Washer M8 WK04-00014
142. Brush holder WK04-00100 170. Bolt M8x30 WK04-00018
143. Brush WK04-00101 171. Bolt M4x12 WK04-00123
To Next Page
