30
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
65. Movable vice jaw WK04-00047 92.1. Washer M8 WK04-00014
66. Bolt M12x40 WK04-00048 93. Bolt M10x45 WK04-00065
67. Washer M12 WK04-00049 94. Washer M10 WK04-00046
68. Fixed vice jaw WK04-00050 94.1. Nut M10 WK04-00052
69. Bolt M10x20 WK04-00051 95. Bolt M8x16 WK04-00013
70. Washer M10 WK04-00046 96. Washer M8 WK04-00014
71. Nut M10 WK04-00052 97. Blade guard WK04-00066
72. Spring support WK04-00053 97.1. Pulley cover WK04-00067
73. Bolt WK04-00054 98. Bolt M8x16 WK04-00013
74. Spring WK04-00055 99. Washer M8 WK04-00014
75. Bolt M10x40 WK04-00056 100. Bolt M8x20 WK04-00068
76. Nut M10 WK04-00052 101. Large washer M8 WK04-00069
77. Bolt M10x35 WK04-00045 102. Bearing 6203ZZ WK04-00070
78. Pivot arm plate WK04-00057 103. Idle blade pulley WK04-00071
79. Pivot arm WK04-00058 103.1. Drive blade pulley WK04-00072
80. Bed shaft WK04-00059 104. Blade
Contact
Distributor
81. Sleeve WK04-00060 105. Idle pulley sleeve WK04-00073
82. Washer M16 WK04-00061 106. Saw bow WK04-00074
83. Nut M10 WK04-00052 107. Blade tensioning knob WK04-00075
84. Support WK04-00062 108. Spring WK04-00076
85. Bolt M10x40 WK04-00056 109. Plate WK04-00077
86. Nut M10 WK04-00052 110. Washer M6 WK04-00011
87. Bolt M10x35 WK04-00045 111. Bolt M6x16 WK04-00010
88. Washer M10 WK04-00046 112. Idle pulley shaft WK04-00078
89.
Bottom support for
hydraulic cylinder
WK04-00063 113. Idle pulley shaft seat WK04-00079
90. Bolt M8x30 WK04-00018 114. Pin 4x20 WK04-00080
91. Shaft for hyd. cylinder WK04-00064 115. Moving plate WK04-00081
92. Bolt M8x16 WK04-00013 116. Bolt M8x16 WK04-00013
7
CAUTION: The warnings and cautions mentioned in this user manual can not cover all possible
conditions and situations that may occur. It must be understood by the operator that com-
mon sense and caution are factors which cannot be built into this product, but must be ap-
plied.
SAFETY INSTRUCTIONS….cont
and safest performance.
ALWAYS wear approved eye and ear protection when operating the machine.
If any dust is produced, wear an approved face or dust mask.
WARNING! round bar and tubing have a tendency to roll whilst being cut and can
cause the blade to slip, DO NOT cut such items without clamping or blocking the
material.
DO NOT start the bandsaw until the material is secure and the blade has been low-
ered to just above the material.
NEVER use damaged or deformed bandsaw blades.
ALWAYS secure the material that is too be cut in the vice.
NEVER use the bandsaw with the blade guard or pulley cover removed.
DO NOT use whilst under the influence of drugs, alcohol or other intoxicating medi-
cation.
NEVER start the bandsaw with the blade in contact with the workpiece.
ALWAYS allow the bandsaw to reach full speed before commencing the cutting op-
eration.
NEVER use this bandsaw for any application other than that specified by the manu-
facturer.
Never operate this bandsaw under conditions not approved by the manufacturer.
Before using or servicing your bandsaw, read and understand all instructions. Failure
to follow safety precautions or instructions can cause equipment damage and/or
serious personal injury.
WEAR THE CORRECT CLOTHING. Do not wear loose clothing, neckties, rings, brace-
lets, or other jewellery, which may get caught in moving parts. Non-slip footwear is
recommended. Wear protective hair covering to contain long hair. Roll long sleeves
up above the elbow.
If the bandsaw is used in a place of work all rules and laws etc. relating to the use of
portable electrical appliances should be followed.
When using the saw, particularly during extended periods; ensure the opera-
tor as well as those in the area wear ear protection.
When using the saw always ensure the operator as well as those in the area
wear eye protection.
Some materials have the potential to be highly toxic; always wear a face
mask when operating the saw.
