ELECTRICAL CONNECTION
WARNING! It is the responsibility of the owner and the operator to read, understand
and comply with the following:
You must check all electrical products, before use, to ensure that they are safe.
You must inspect power cables, plugs, sockets and any other connectors for wear or
damage.
You must ensure that the risk of electric shock is minimised by the installation of appro-
priate safety devices; A residual current circuit Breaker (RCCB) should be incorporated
in the main distribution board. We also recommend that a residual current device
(RCD) is used. It is particularly important to use an RCD with portable products that are
plugged into a supply which is not protected by an RCCB. If in any doubt consult a
qualified electrician.
Connecting to the 1 phase power supply:
This SIP bandsaw is fitted with a standard 230v ~ 13 amp type plug. Before using the
bandsaw, inspect the mains lead and plug to ensure that neither are damaged. If
any damage is visible have the bandsaw inspected / repaired by a suitably qualified
person. If it is necessary to replace the plug a heavy duty impact resistant plug would
be preferable.
The wires for the 1 phase plug are coloured in the following way:
Yellow / green Earth
Blue Neutral
Brown Live
As the colours of the wires may not correspond with the markings in your plug, pro-
ceed as follows: The wire which is coloured blue, must be connected to the terminal
marked with N or coloured black. The wire which is coloured brown, must be connect-
ed to the terminal, which is marked L or coloured red. The wire which is coloured yel-
low / green should be connected to the terminal which is coloured the same or
marked
Always secure the wires in the plug terminal carefully and tightly. Secure the cable in
the cord grip carefully.
Connecting to the 3 phase power supply:
The 3ph bandsaw comes with no plug fitted, the cable will have 3 phases and an
earth, this should be, where possible, hard wired into the mains board, always use a
29
PARTS LIST
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Bottom pan WK04-00001 37. Hose WK04-00025
2. Left leg WK04-00002 38. Handle WK04-00026
3. Right leg WK04-00003 39. Vice hand-wheel WK04-00027
4. Front panel WK04-00004 40. Bolt M6x6 WK04-00028
5. Middle pan WK04-00005 41. Key 5x20 WK04-00029
6. Wheel 125x12mm WK04-00006 42. Lead screw WK04-00030
7. Pin 25x3 WK04-00007 43. Acme nut seat WK04-00031
8. Axle WK04-00008 44. Bolt M6x16 WK04-00010
14. Hydraulic cylinder WK04-00009 45. Acme nut WK04-00032
17. Bolt M6x16 WK04-00010 46. Pin WK04-00033
18. Washer M6 WK04-00011 47. Spring screw WK04-00034
19. Nut M6 WK04-00012 48. Bolt M5x8 WK04-00035
20. Bolt M8x16 WK04-00013 49.
End of cut
microswitch housing
WK04-00036
21. Washer M8 WK04-00014 50. End of cut microswitch WK04-00037
22. Nut M8 WK04-00015 51. Washer M6 WK04-00011
23. Bolt M6x20 WK04-00016 52. Bolt M6x12 WK04-00038
25. Filter WK04-00017 53.
Thumb screw
for cut off stop
WK04-00039
26. Nut M6 WK04-00012 54. Cut off stop WK04-00040
27. Bolt M8x30 WK04-00018 55. Cut off stop shaft WK04-00041
28. Washer M8 WK04-00014 56. Bolt M8x16 WK04-00013
29. Nut M8 WK04-00015 57. Washer M8 WK04-00014
31. Coolant tank WK04-00020 58. Nut M8 WK04-00015
32. Hose WK04-00021 59. Support plate WK04-00042
33. Coolant pump 1 phase WK04-00022 60. Bolt M8x30 WK04-00018
33. Coolant pump 3 phase WK04-00330 61. Bed WK04-00043
34. Bolt M6x16 WK04-00010 62. Lever lock WK04-00044
35. Hose fitting WK04-00023 63. Bolt M10x35 WK04-00045
36. Hose clamp WK04-00024 64. Washer M10 WK04-00046
