12
ELECTRICAL CONNECTION….cont
3PH Wiring: 01708 only.
WARNING! It is the responsibility of the owner and the operator to read, understand
and comply with the following:
You must check all electrical products, before use, to ensure that they are safe.
You must inspect power cables, plugs, sockets and any other connectors for wear or
damage.
You must ensure that the risk of electric shock is minimised by the installation of appro-
priate safety devices; A residual current circuit Breaker (RCCB) should be incorporated
in the main distribution board. We also recommend that a residual current device
(RCD) is used. It is particularly important to use an RCD with portable products that are
plugged into a supply which is not protected by an RCCB. If in any doubt consult a
qualified electrician.
Connecting to the power supply:
The SIP 01708 F32-20 pillar drill requires 400v 50hz supply. Before each use, inspect the
mains lead and plug (where applicable) to ensure that neither are damaged. If any
damage is visible have the pillar drill inspected / repaired by a suitably qualified per-
son. If it is necessary to replace the plug a heavy duty impact resistant plug would be
preferable.
The wires for the plug are coloured in the following way:
Yellow / green Earth
Blue/Grey Phase
Brown Phase
Black Phase
Always secure the wires in the plug terminal carefully and tightly. Secure the cable in
the cord grip carefully.
Warning: Never connect live, neutral or any phase wires to the earth ter-
minal of the plug. Only fit an approved plug with the correct rated fuse. If
in doubt consult a qualified electrician.
Warning: Always use a qualified electrician to wire in the 3ph pillar drill, never
wire the pillar drill without any knowledge of electrics, this is extremely danger-
ous and will cause personal injury or even death.
49
PARTS LIST - 01706….cont
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
68. Circlip WD01-00713 98. Spring washer M16 WD01-00853
69. Spindle shaft WD02-00309 99. Lock handle WD02-00322
70. Bearing 6005 WD01-00889 100. Worm pin WD02-00323
71. Bearing ring WD02-00191 101. Table support WD02-00324
72. Screw (M8 x 25) WD01-00891 102. Bolt (M6 x 12) WD01-00905
73. Casting WD02-00311 103. Crank handle WD02-00325
74. Label WD02-00312 104. Circlip WD01-00742
75. Lock washer WD01-00725 105. Worm shaft WD02-00207
76. Clip WD01-00724 106. Worm gear WD02-00208
77. Screw (M5 x 6) WD01-00894 107. Locking handle WD01-00852
78. Tension spring WD02-00313 108. Angle label WD02-00328
79. Tension spring cover WD02-00314 109. Lamp socket WD01-00837
80. Nut M12 WD01-00821 110. Chuck guard 65mm 07664
81. Switch box WD02-00315 111. Drift key WD01-00862
82. Switch WD01-00895 112. Hex. wrench 4mm WD01-00737
83. Screw (M3 x 10) WD01-00896 113. Hex. wrench 6mm WD01-00861
84. Mains lead clamp WD01-00700 100. Worm pin WD02-00323
85. Mains lead WD01-00720 101. Table support WD02-00324
86. Indicator WD01-00897 102. Bolt (M6 x 12) WD01-00905
87. Circlip WD01-00787 103. Crank handle WD02-00325
88. Bearing 6203 WD01-00714 104. Circlip WD01-00742
89. Quill WD02-00316 105. Worm shaft WD02-00207
90. Spindle WD02-00317 106. Worm gear WD02-00208
91. Bearing 6006 WD01-00900 107. Locking handle WD01-00852
92. Washer WD01-00901 108. Angle label WD02-00328
93. Arbor WD02-00318 110. Chuck guard 65mm 07664
94. Chuck WD02-00319 111. Drift key WD01-00862
95. Table WD02-00320 112. Hex. wrench 4mm WD01-00737
96. Table arm WD02-00321 113. Hex. wrench 6mm WD01-00861
97. Bolt (M16 x 30) WD01-00854
