6
SAFETY INSTRUCTIONS….cont
accessories. The use of improper accessories may cause hazards and will invalidate
any warranty you may have.
REMOVE ADJUSTING KEYS AND WRENCHES: Form a habit of checking to see that keys
and adjusting wrenches are removed from the drill before every use.
SECURE THE WORKPIECE: Use clamps or a vice to hold the workpiece. This frees up
both hands to operate the pillar drill.
DO NOT OVERREACH: Keep proper footing and balance at all times.
USE THE RIGHT TOOL: Do not use the drill or attachment to do a job for which it was not
designed.
DO NOT FORCE THE PILLAR DRILL: It will do the job better and more safely at the rate
which it was designed.
DO NOT OPERATE THE PILLAR DRILL IN EXPLOSIVE ATMOSPHERES: Do not use the drill in
the presence of flammable liquids, gases, dust or other combustible sources. Drilling
operations may create sparks which can ignite the dust or fumes.
DO NOT EXPOSE THE PILLAR DRILL TO RAIN OR USE IT IN WET CONDITIONS: Water enter-
ing pillar drill will greatly increase the risk of electric shock.
HAVE YOUR PILLAR DRILL REPAIRED BY A QUALIFIED PERSON: The tool is in accordance
with the relevant safety requirements. Repairs should only be carried out by qualified
persons using original spare parts, otherwise this may result in considerable danger to
the user.
DO NOT dismantle, tamper with or use the drill without all guards fitted as this may be
dangerous and will invalidate the warranty.
Keep hands away from the path of the drill bit, never reach around the drill bit.
Make sure the drill bit is clear of the workpiece before the switch is turned on.
Allow the drill bit to run up to full speed before drilling.
Stop operation immediately if you notice anything abnormal.
Wait for the drill bit to stop completely and remove the plug from mains supply be-
fore servicing or adjusting the drill or changing bits.
Be alert at all times, especially during repetitive, monotonous operations. Don't be
lulled into a false sense of security. Drill bits can be extremely unforgiving.
Use of improper accessories may cause damage to the drill and surrounding area
as well as increasing the risk of injury.
Turn off the drill and wait for it to completely stop before moving workpiece or
changing settings or bits etc.
Do not modify the pillar drill to do tasks other than those intended.
When drilling, particularly hard items such as metal, use clamps to hold the work-
piece; To avoid injury, the work should never be held with the bare hands.
Secure the base of the drill to a work bench or the floor before using the pillar drill. If
the work is heavy or large and likely to cause the drill to tip over, use additional sup-
ports as appropriate under and around the workpiece.
55
PARTS LIST - 01708….cont
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
67. Nut M5 WD01-00697 92. Nut WD02-00380
68. Microswitch holder WD01-00709 93. Washer M6 WD01-00702
69. Washer M6 WD01-00702 94. Screw (M6 x 12) WD02-00381
70. Spring washer M6 WD01-00707 95. Screw (10 x25) WD02-00382
71. Nut M6 WD01-00710 96. Casting WD02-00383
72. Cam assembly WD02-00368 97. Spindle pulley WD02-00384
73. Screw (M5 x 16) WD01-00838 98. Key WD02-00385
74. Washer WD01-00881 99. Spindle shaft WD02-00386
75. Protecting ring WD01-00839 100. Bearing 6007 WD02-00387
76. Pulley cover WD02-00369 101. Ring WD02-00388
77. Washer M8 WD01-00672 102. Circlip WD02-00389
78. Bolt (M8 x 10) WD02-00370 103. Screw (M4 x 60) WD02-00434
79. Clamp WD02-00371 104. Spring washer (M4) WD02-00435
80. Overload 5A WD02-00432 105. Washer (M4) WD02-00436
81. Lock washer WD02-00433 106. Washer WD02-00437
82. Eccentric shaft WD02-00374 107. Quill WD02-00393
83. Centre pulley WD02-00375 108. Bearing 51107 WD02-00394
84. Bearing 6202 WD01-00771 109. Spindle WD02-00395
85. Circlip WD01-00831 110. Arbor MT4 17823
86. Belt A686 WD02-00376 111. Chuck WD02-00396
87. Protecting ring WD01-00770 112. Chuck guard 75mm 68328
88. Clamp WD02-00377 113. Drift key WD01-00862
89. Mains lead WD01-00720 114. Switch WD02-00430
90. Tension spring WD02-00378 115. Label WD02-00438
91. Tension spring cover WD02-00379 116. Switch box WD02-00439
