8
Part number 01700 01701 01702
Model B13-13 B16-12 B16-16
Input Voltage 230v ~ 50hz 230v ~ 50hz 230v ~ 50hz
Power 350 w 375 w 375 w
Speed Range 620-2620 rpm 300-2550 rpm 180-2770 rpm
Number of Speeds 5 12 16
Drill Bit Size 1.5-13 mm 3-16 mm 3-16 mm
Max. Drilling Capacity (mild Steel) 13 mm 16 mm 16 mm
Spindle Taper B16 B16 MT2
Table Size 160 x 160 mm 202 x 195 mm Ø 290 mm
Base Size 290 x 190 mm 340 x 210 mm 415 x 245 mm
Column Ø 46 mm 58 mm 72 mm
Swing 210 mm 260 mm 325 mm
Height 580 mm 840 mm 980 mm
Spindle Travel 50 mm 60 mm 80 mm
Collar Ø 40 mm 40 mm 55 mm
Max. Distance Chuck to Table 220 mm 405 mm 450 mm
Max. Distance Chuck to Base 300 mm 515 mm 630 mm
Net Weight 14.7 Kg 27 Kg 38 Kg
Gross Weight 16.7 Kg 29 Kg 40 Kg
