30
PARTS LIST - 01700
Ref. No. Description SIP Part No. Ref. No. Description SIP Part No.
1. Base WD01-00670 34. Screw (M6 x 10) WD01-00703
2. Column flange WD01-00671 35. Circlip WD01-00704
3. Washer 8mm WD01-00672 36. Knurled screw WD01-00705
4. Spring washer 8mm WD01-00673 37. Microswitch WD01-00706
5. Bolt (M8 x 20) WD01-00674 38. Washer 6mm WD01-00702
6. Bolt (M12 x 30) WD01-00675 39. Spring washer 6mm WD01-00707
7. Spring washer 12mm WD01-00676 40. Screw (M6 x 16) WD01-00708
8. Table WD01-00677 41. Microswitch holder WD01-00709
9, Table support WD01-00678 42. Nut M6 WD01-00710
10. Angle label WD01-00679 43. Grub screw (M6 x 10) WD01-00711
11. Locking handle WD01-00680 44. Motor pulley WD01-00712
12. Column WD01-00681 45. Circlip WD01-00713
13. Handle knob WD01-00682 46. Bearing WD01-00714
14. Handle WD01-00683 47. Spindle shaft WD01-00715
15. Handle shaft WD01-00684 48. Spindle pulley WD01-00716
16. Warning label WD01-00685 49. Belt K630 18090
17. Screw (M8 x 16) WD01-00686 50. Nut M10 WD01-00717
18. Nut M8 WD01-00687 51. Spring cover WD01-00718
19. Casting WD01-00688 52. Spring WD01-00719
20. Grub screw (M8 x 20) WD01-00689 53. Mains lead WD01-00720
21. Knob WD01-00690 54. Screw (M4 x 12) WD01-00721
22. Motor spring WD01-00691 55. Switch WD01-00722
23. Motor push rod WD01-00692 56. Screw (M4 x 6) WD01-00723
24. Washer WD01-00693 57. Clip WD01-00724
25. Motor WD01-00694 58. Lock washer WD01-00725
26. Bolt (M8 x 25) WD01-00695 59. Screw (M5 x 10) WD01-00726
27. Washer WD01-00696 60. Mains lead clamp WD01-00700
28. Nut M5 WD01-00697 61. Label WD01-00728
29. Pulley cover WD01-00698 62. Label WD01-00729
30. Protecting ring WD01-00699 63. Indicator WD01-00730
31. Mains lead clamp WD01-00700 64. Limit bolt WD01-00731
32. Screw (M5 x 12) WD01-00701 65. Bearing 6201 WD01-00732
33. Washer 6mm WD01-00702 66. Washer WD01-00733
