SILVERCUT
3
INDEX
Prologue 2
Ordering of spare parts 2
General safety instructions 4
Regular use in agriculture 4
Safety and antiaccident instructions 4
On tractor mounted machines 5
P.T.O. SHAFT drive (only for implements driven
by a P.T.O Shaft) 5
Hydraulics 5
Maintenance 6
1. Foreword 7
1.1 Position of safety decals with warning text
on the machine 7
1.3 Technical data 11
1.4 Calculation of tractor ballast 12
2. Preparing 14
2.1 Special safety instructions 14
2.2 Attaching to the tractor 14
2.2.1 Transverse adjustment of the hitch 15
2.2.2 Parallel hitch adjustment – at the same time
the grass cut height adjustment 15
2.2.3 Adjusting the working height of the
connection 16
2.3 P.T.O.shaft 16
2.3.1 General 16
2.3.2 P.T.O. shaft length adjustment 17
2.3.3 Mounting the cardan shaft 17
2.4 Hydraulic hitch up 18
2.5 Placing the string for cutter bar protection
in the transport position into the tractor's
cabine 18
2.6 Connection of lighting equipment 18
3. Preparation of a mower for mowing 19
3.1 Adjusting the hydraulic discharge of the
cutter bars 19
4. Preparing the mower for work and transport
position 20
5. Mowing 21
5.1 Lifting the cutter bars when driving into new
row 22
5.2 Caution when mowing in inclination 22
5.3 Protecting the mower 23
6. Disconnecting the mower from the tractor 23
6.1 Disconnecting the mower from the tractor
with cutter bars in work position 23
6.2 Disconnecting the mower from the tractor
with cutter bars in transport position 24
7. Maintenance and periodical overhauls 25
7.1 Special safety instructions 25
7.2 General 25
7.3 Replacing the blades 26
7.4 Replacing the protective curtain 27
7.5 Replacing the blade holders, mower blade
and screw 29
7.6 Replacement of safety pins on individual
disks 30
7.7 Lubrication 32
8. Wintering 43
9. Restart for a new season 43
10. Sonderausrüstung / Zusatzteile 43
10.1 Replacing the blades by screwing 43
