H:\DESSIN\DEPTDESS-2\PLAN ÉLECTRIQUE\006 + PART LIST 2010\PART LIST SANS MODEL ET MANUFACTURIER.xls
# PART PART MACHINE MACHIN
E
REF. OPT. QTY
SIPRO DESCRIPTION APPLICATION VOLTAGE
036-1500 MALE PLUG 15 AMP./ 125 V. SUPPLY 120V/1PH/60HZ 350 GND-L1-N 1
030-0120 CAB TIRE SUPPLY 120V/1PH/60HZ 350 GND-L1-N 3 M.
028-0105 GROUND BARRIER (6 HOLES) SUPPLY ALL 350 GND 1
034-0755 FUSE HOLDER 30A 1 PÔLE VACUUM KB-20 120V/1PH/60HZ 350 F1 1
034-0530 FUSE MIDGET 20A/250V TIME-DELAY VACUUM KB-20 120V/1PH/60HZ 350 F1 1
025-0030
MOTOR CONTACTOR
1HP IN 120V-CSA,UL
VACUUM KB-20 120V/1PH/60HZ 350 C1 1
025-0190
THERMAL OVERLOAD
12 TO 18A-CSA,UL
VACUUM KB-20 120V/1PH/60HZ 350 O/L1 1
030-0430 TEW #14/41 BLACK VACUUM KB-20 120V/1PH/60HZ 350 WM1 1M.
030-0440 TEW #14/41 GREEN VACUUM KB-20 120V/1PH/60HZ 350 WM1 0.5M.
125-1020
V
ACUUM PUMP 110-120V/1PH/60HZ 0.75KW 13A
VACUUM KB-20 120V/1PH/60HZ 350 M1 1
034-0755 FUSE HOLDER 30A 1 PÔLE SEALING 120V/1PH/60HZ 350 F2 1
034-0450 FUSE MIDGET 7A/250V TIME-DELAY SEALING 120V/1PH/60HZ 350 F2 1
025-0020
CONTACTOR
ITH=25A-CSA,UL
SEALING 120V/1PH/60HZ 350 C2 1
029-0014 TRANSFO 250VA, 120V/24V 60HZ SEALING 120V/1PH/60HZ 350 TR2 1
027-0220
TERMINAL ROUND STUD #10
600v 75°C
SEALING ALL 350 WEL 2
030-0410 TEW #10/104 BLACK SEALING ALL 350 WEL 1.5M.
027-0065 TERMINAL FLAG FEMALE YELLOW .250'' SEALING ALL 350 WEL 2
005A0046 SEAL BAR ASSEMBLY W/SUPPORT SEALING TWIN SEAL ALL 350 A1 1
005A0558 SEAL BAR ASSEMBLY W/SUPPORT SEALING BAG CUT ALL 350 A2 1
034-0740 FUSE HOLDER M4/8SF CONTROL TRANSFO 120V/1PH/60HZ 350 F5 1
034-0200 FUSE 5X20MM 3/4A 250V T-DELAY CONTROL TRANSFO 120V/1PH/60HZ 350 F5 1
029-0008 TRANSFO 65VA/120V/24-9V CONTROL TRANSFO 120V/1PH/60HZ 350 TR1 1
034-0740 FUSE HOLDER M4/8SF CONTROL 9VAC+24VAC ALL 350 F3+F4 2
034-0210 FUSE 5X20MM 2A/250V TIME DELAY CONTROL 9VAC ALL 350 F3 1
034-0240 FUSE 5X20MM 4A/250V TIME DELAY CONTROL 24VAC ALL 350 F4 1
030-0590 20AWG/12COND.PVC,UNSHIELD.300V OUTPUT CONTROL ALL 350 W001 1M.
036-0740 12 CONTACTS CONNECTOR OUTPUT CONTROL ALL 350 JP3/1-2 1
030-0631 22AWG/4COND.PVC,SHIELDED,300V. INPUT CONTROL ALL 350 WCV 2M.
036-0820 0.156'' CENTERLINE CRIMP HOUSING INPUT CONTROL ALL 350 JP4 1
036-0850 0.156'' CENTERLINE CRIMP TERMINAL INPUT CONTROL ALL 350 JP4 2
033-0038 MICROPROCESSOR MC-40 SENSOR VACUUM CONTROL WITH SENSOR ALL 350 MC-40 B1 1
033-00385 MICROPROCESSOR MC-40 NO SENSOR VAC. CONTROL W/O SENSOR ALL 350 MC-40 B2 1
033-0015 MEMBRANE MC-40 SIPROMAC CONTROL SIPROMAC ALL 350 C1 1
033-0018 MEMBRANE MC-40 BERKEL CONTROL BERKEL ALL 350 C2 1
106-0020 VALVE 2WAY 24V 1/2 NPT(G94) 60HZ ATMOSPHERE ALL 350 F 1
106-0070 VALVE 3WAY 24V 1/4 NPT(G176)60HZ BELLOWS ALL 350 G 1
106-0010 VALVE 2WAY 24V 1/4 NPT(G22) 60HZ OPTION GAS ALL 350 H D 1
004-0261
LIMIT SWITCH ASSY
15A 250V
COVER POSITION ALL 350 CV 1
036-1512 MALE PLUG 15 AMP./ 250 V. SUPPLY 220V/1PH/60HZ 350 GND-L1-L2 1
