INTRODUCTION
This manual has been written to provide the client with all information concerning the
machine and the norms pertaining to it, apart from the use and maintenance instructions which
enable it to be used in the best way possible, therefore maintaining its efficiency through time.
This manual must be given to all personnel who will use or do maintenance on the machine.
INDEX OF CHAPTERS
CHAP. 1 - MACHINE INFORMATION page 4
1.1 - GENERAL PRECAUTIONS
1.2 - SAFETY DEVICES INSTALLED ON THE MACHINE
1.3 - DESCRIPTION OF THE MACHINE
1.3.1 - General description
1.3.2 - Constructive features
1.3.3 - Machine makeup
CHAP. 2 - TECHNICAL DATA page 6
2.1 - DIMENSIONS, WEIGHT, CHARACTERISTICS ...
CHAP. 3 - RECEIVING THE MACHINE
page 8
3.1 - SHIPPING THE MACHINE
3.2 - CHECKING THE PACKAGE UPON RECEIPT
3.3 - DISPOSING OF THE PACKAGE
CHAP. 4 - INSTALLATION
page 9
4.1 - MACHINE PLACEMENT
4.2 - ELECTRICAL CONNECTIONS
4.2.1 - PPJ/LCJ SC with single-phase motor
4.2.2 - PPJ/LCJ SC with three-phase motor
4.3 - ELECTRICAL DIAGRAMS
4.3.1 - Diagram of electrical system single-phase
4.3.2 - Diagram of electrical system three-phase
4.4 - OPERATIONAL CHECK
CHAP. 5 - MACHINE USE
page 12
5.1 - CONTROLS
5.2 - LOADING AND WORKING THE PRODUCT
CHAP. 6 - ROUTINE CLEANING page 13
6.1 - GENERALITIES
