KEY:
1. Hopper
2. Cover block hinge
3. Pan
4. Pan block hinge
5. Feet
6. Controls
7. Flanged feet
8. Structure
9. Discharge door
10. Cover
11. Water inlet
12. Stand
13. Sieve
NB: there is the possibility of adding the sieve to the
stand to collect waste.
1.3.3 - Machine makeup
FIG. n°1 - General view of the machine
2
6
1
4
5
8
3
7
9
11
10
