Siruba C007K User Manual

15
6. General Parameter Table :
Mode
Parameter
Code
Parameter Function
Range /
Selection
Description / Note
001. H
Maximum sewing speed ( spm )
50 ～ 9999
Maximum speed adjustments.
004. N
Start Back-Tacking speed or
Constant-Stitch speed for the
Interlock Stitch machine (
spm )
50 ～ 8000
Speed adjustment for Start Back-Tacking or Constant-Stitch
sewing in the Interlock Stitch machine.
005. V
End Back-Tacking speed ( spm )
50 ～ 8000
Speed adjustment for End Back-Tacking.
006. B
Bar-Tacking speed ( spm )
50 ～ 8000
Speed adjustment for Bar-Tacking.
007. S
Slow Start speed ( spm )
50 ～ 2000
Speed adjustment for Slow Start.
008. S L S
Number of Stitches for the Slow Start
0 ～ 99
Number of Stitches setting for Slow Start.
009. A
Automatic Constant-Stitch sewing
speed or Auto-start testing speed
( spm )
50 ～ 8000
Speed adjustment for Automatic Constant-Stitch sewing.
Note：Valid only when the【 037. SMP】 set on 『A 』
010. A C D
Automatic End Back-Tacking sewing
(Can invalidate the Stitch Correction function)
ON / OFF
O
N：After last seam of Constant-Stitch sewing, it will automatic
execute the End Back-Tacking sewing function.
Note：When turned on, the Stitch-Correction is invalid.
OFF：Automatic End Back-Tacking will not execute after last seam,
but can be done by pedal manually
Note：The Stitch-Correction is valid in Free sewing, but the
parameter 【011.RVM】 must set on『
B 』.
011. RVM
Back-Tacking Mode selection
J / B
J
：JUKI mode ( Press TB switch will activate the reverse solenoid
when either machine is stopped or running).
B：BROTHER mode (Press TB switch will activate the reverse
solenoid only when machine is running).
040. W O N
Wiper function selection ON / OFF
O N
：Wiper valid.
OFF：Wiper invalid.
041. T M
Trimmer function selection ON / OFF
O
N：Trimmer valid.
OFF：Trimmer invalid.
045. S P
Sewing speed 0~8000
Showing the current sewing speed.
A
046. D I R
Direction of motor rotation CW / CCW
C W ：Clockwise.
CCW：Counterclockwise.
060. L
Low speed ( spm )
50 ～ 500
Speed adjustment for Low speed.
061. T
Trimmer speed ( spm )
50 ～ 500
Speed adjustment for Trimmer.
064. F O
Full-On time setting for Automatic
Foot Lifter ( ms )
0 ～ 990
Timing adjustment for Full-On time of Automatic Foot Lifter actives.
065. F C
Duty-Cycle setting for Automatic
Foot Lifter ( ％ )
10 ～ 90
Adjustment for Duty-Cycle of AFL.
(Fine tuning can reduce the over heating)
066. F D
Running-Delay time setting (ms )
0 ～ 990
Running-Delay time adjustment for the Automatic Foot Lifter.
070. H H C
Cancel Automatic Foot Lifting when
Half-Heeling the pedal
ON
/ OFF
O N
：Pedal half heeling without foot lifting function.
(Only full heeling can activate Foot Lifer.)
OFF：Pedal half heeling with foot lifting function.
075. S F M
Safety switch mode NC / NO
NO：Means Normal Opened.
NC：Means Normal Closed.
083. T 2
Trimming timing (ms)
0 ～ 990
Adjustment for trimming timing
087. L 2
Tension release timing (ms)
0 ～ 1500
Adjustment for tension release timing.
093. W 2
Wiper timing (ms)
0 ～ 9990
Adjustment for wiper timing.
119. DD
Motor drive mode ON / OFF
O
N：Motor drive machine head directly
OFF：Motor drive machine head with belt.
B
121. A N U
Needle goes up automatically as
power turned on
ON
/ OFF
O
N：Power turned on, needle goes up position automatically.
OFF：No Use.
122. HL
Upper limit of maximum speed 50 - 9999 The motor's maximum speed setting.
