6. Table of commonly used Parameters:
Parameters Code
Actual
value
Display
value
Code
Definition of Parameter
Calibration
range
Unit
Press P Key
01 01 H
Maximum sewing speed.
100-5000 spm *100
02 02 SLM
Mode of slow start
A/T ---
03 03 CNR
Setting of counter ratio.
1-9 *1
07 07 S
Speed of slow start.
100-500 spm *10
08 08 SLS
Stitch numbers of slow start.
1-9 stitches *1
09 09 A
Speed of automatic operation.
100-5000 spm *100
40 40 WON
Selection of wiper function.
ON/OF ---
41 41 TM
Selection of trimmer sequence.
ON/OF ---
45 45 SP
Display of sewing speed.
0-8000 spm *100
46 46 DIR
Rotation direction of motor.
CC/CW ---
Press P Key + Power ON
47 47 MAC
Machine Code.
--- ---
60 60 L
Minimum speed.
100-500 spm *10
61 61 T
Speed of thread-trimming.
100-500 spm *10
64 64 FO
Setting of time of full output for foot-lifting
solenoid.
0-990 ms *10
65 65 FC
Setting of time of duty cycle for
foot-lifting solenoid.
10-60% *1
66 66 FD
Setting of delay time of motor operation.
0-990 ms *10
70 70 HHC
Cancellation of function of raising
pressure foot lifter by half-heeling
backward.
ON/OF ---
75 75 SFM
Mode selection of safety switch
NC/NO ---
122 22. HL Upper limit of maximum speed. 100-5000 spm *100
※
Displaying parameter number 00.=100, 0.0=200, 0.0.=300; for example: 06.=106 parameter.
※The setting values may vary depending on the
model.
