Sit 710 MINISIT - Dimensions; Gas Flow as a Function of Pressure Loss

DIMENSIONS
GAS FLOW AS A FUNCTION OF PRESSURE LOSS
0
5
10
Q [m
3
/h d=0.6]
4
2
6
∆p [mbar]
I Family (d = 0.45) Q = 3.9 m
3
/h ∆p = 5 mbar
II Family (d = 0.6) Q = 3.5 m
3
/h ∆p = 5 mbar
III Family (d = 1.7) Q = 4.4 kg/h ∆p = 5 mbar
