INSTALLATION
Main gas connection
The connection must be made using gas pipes with 1/2 or 3/8 inlet and 3/8 outlet Rp ISO 7.
Torque: 25 Nm. Alternatively, it is possible to use a nut and olive connection for Ø 12 mm
pipes (Codes 0.958.025 and 0.957.007) (torque 15 Nm).
Connection to the pilot burner
Ø 4 mm, Ø 6 mm or Ø 1/4” pipes can be used. Use appropriately sized nut and olive.
Tighten to 7 Nm torque. After making the gas connection, check gas seals and efficiency
of the appliance.
