Page 10 210-PMTXM Issue L www.skcltd.com
Air Inlet Port Air Inlet Port Air Exhaust Port
(210-1003MTX only)
Belt Clip
Slide Cover
(Open Position)
Keypad
LCD Screen
PC Interface
Connector
Inlet
Particulate
Filter*
*At base of inlet port
Battery Pack
Charging Jack
Socket
Diagram of the Pocket Pump
