www.skcltd.com 210-PMTXM Issue L Page 11
Pocket Pump LCD Screen
Operating Indicators
Display Units
Numerals
Flow Fault Indicator
Battery Charge Status
Operating Indicators
PROG
Active when a program is loaded into the pump memory using the DataTrac interface and software
HOLD
Flashes when the pump is the HOLD state
ADJ
Flashes when adjusting the pump flow rate during flow calibration
FLOW
Active when the pump LCD screen displays the flow rate
VOL
Active when the pump LCD screen displays the volume of air sampled
SET
Flashes when setting the pump flow rate or back pressure setting
Display Units
°C or °F Sample air temperature in degrees Centigrade or Farenheit (Enhanced Display Mode only)
ins or mm Pump back pressure in inches of water or millimetres of mercury (Enhanced Display Mode only)
mL/min
Pump flow rate in millilitres per minute
mL or L Total volume of air sampled in millilitres or litres since last reset
min
Run time in minutes since last reset
