SKF CMPT CTU User Manual

CMPT CTU Output Signal Scales
Vibration
SKF Copperhead Transmitter Unit CMPT CTU6-14
Instruction Manual
The following Table 6-1 lists the vibration gain (unit/V) and scale values of Velocity
mode, ISO and Non-standard ISO.
Sensor (RMS)
RANGE 0
RANGE 1
RANGE 2
RANGE 3
230 mV/g
Metric (RMS)
Gain
Scale
0,065 mm/s/V
0 to 0,65 mm/s
0,22 mm/s/V
0 to 2,17 mm/s
0,65 mm/s/V
0 to 6,5 mm/s
2,2 mm/s/V
0 to 21,74
mm/s
100 mV/g
Metric (RMS)
Gain
Scale
0,15 mm/s/V
0 to 1,50 mm/s
0,50 mm/s/V
0 to 5,00 mm/s
1,5 mm/s/V
0 to 15,00
mm/s
5,0 mm/s/V
0 to 50 mm/s
30 mV/g
Metric (RMS)
Gain
Scale
0,5 mm/s/V
0 to 5 mm/s
1,67mm/s/V
0 to 16,7 mm/s
5,0 mm/s/V
0 to 50 mm/s
16,7 mm/s/V
0 to 167 mm/s
10 mV/g
Metric (RMS)
Gain
Scale
1,5 mm/s/V
0 to 15 mm/s
5,0 mm/s/V
0 to 50 mm/s
15 mm/s/V
0 to 150 mm/s
50 mm/s/V
0 to 500 mm/s
Sensor (Peak)
RANGE 0
RANGE 1
RANGE 2
RANGE 3
230 mV/g
English (IPS
Ps. PK)
Gain
Scale
0,0036 IPS/V
0 to 0,036 IPS
0,012 IPS/V
0 to 0,12 IPS
0,036 IPS/V
0 to 0,36 IPS
0,121 IPS/V
0 to 1,21 IPS
100 mV/g
English (IPS
Ps. PK)
Gain
Scale
0,008 IPS/V
0 to 0,08 IPS
0,027 IPS/V
0 to 0,27 IPS
0,084 IPS/V
0 to 0,84 IPS
0,28 IPS
0 to 2,78 IPS
30 mV/g
English (IPS
Ps. PK)
Gain
Scale
0,028 IPS/V
0 to 0,28 IPS
0,093 IPS/V
0 to 0,93 IPS
0,28 IPS/V
0 to 2,8 IPS
0,93 IPS/V
0 to 9,3 IPS
10 mV/g
English (IPS
Ps. PK)
Gain
Scale
0,084 IPS/V
0 to 0,84 IPS
0,28 IPS/V
0 to 2,8 IPS
0,84 IPS/V
0 to 8,4 IPS
2,8 IPS/V
0 to 28 IPS
Table 6-1: Velocity mode, ISO and Non-standard ISO
