3. Overview, functional description
3.1 Progressive metering device overview with universal piston detector 234-13163-9 or bipolar piston detector 234-11454-1
Mounting dimensions for universal and bipolar piston detectors, Fig. 1
VPBM VPK VP SSV
PSG1 PSG2 PSG3 SSVD
/SSVL
/SSVDL
SW 12
44-0159-2507
SW 24
44-0159-2510
SW 13
419-74455-1
53,6 (53,3)
53,5 (53,5)
53,5 (53,5)
53,8 (53,5)
53,8 (53,5)
40 (39,5)
54,3 (54)
54,3 (54)
SW 12
44-0159-2508
SW 12
44-0159-2508
SW 12
44-0159-2509
SW 12
44-0159-2509
SW 13
419-74455-1
(....) = mounting dimension of previous piston detector
