SKF Multilog On-Line System IMx-S 1 - 1
User Manual – Revision S
1
Introduction
Important Messages
The following messages are important information which require special care in order to
have a safe and reliable IMx-S system.
Important messages, instructions and information in this manual must be
carefully followed. Otherwise, harm might occur to equipment and/or personnel.
In order to install an IMx-S32-UPG-LMU (LMU/CMU upgraded to IMx-S32),
installation must be done according to the "IMx-S32-UPG-LMU Installation manual".
In order to fulfil fire enclosure requirements, ensure the following:
- The cabinet must always be mounted using all four supplied mounting brackets.
- All unused cable ways must be closed with the supplied blind plugs.
- All cable glands and blind plugs must be made of material with fire protection V-1
or better.
Important messages related to mains power (see Mains Power section as well):
- In some countries, the installer must be certified to install equipment such as an
IMx-S.
- Make sure that the power is disconnected before the installation begins.
- Mains cable must be properly fixed with a cable gland to prevent the cord from
strain, twist or movement. See Cable Glands section as well.
- To prevent a hazardous event, mains cable neutral (N) and line (L1) wires must be
secured together with a cable tie (for example, a nylon cable tie CV-100K) close to
the mains power connector.
- The system power supply must be provided with an external all pole power switch
so as to be able to disconnect the IMx-S from mains power. The switch must be
labelled "IMx-S” or siilar with the On/Off position clearly marked. The switch
must be located close to the IMx-S, within an operator's easy reach.
